2,000.00 / Piece
| Business Type | Manufacturer, Exporter, Supplier, Trader |
| Country of Origin | India |
| Specialities | Rust Proof, Non Breakable, High Tensile |
| Brand Name | QTC |
| Click to view more | |
Product Details
Surface Finishing
Polished
Strainer Material
CI/CS/SS304/SS316/FABRICATED
Shape
Y TYPE/T TYPE
Color
BLUE/SILVER
Model No
QT 234
Type of Valves
”Y”Type/ ”T” Type / Pot type / Basket Type
Manufacturing Standard / Inspection & Testing
Mfg. Standard/ BS 6755 PART I
End Connection
Screwed To BSP/ BSPT / NPT Scked Weld/ Flanged Ends Butt Weld Ends.
Pressure Rating
ASA 125#/150#/300#/600#/900# PN-10/PN-10/PN-16/ND-40& PN-64
Size Range
15mm to 800mm
Product Code
QT234
Delivery Time
DEPANDS ON QUANTITY
Packaging Details
GUNNY BAG PACKING
Material of Construction: Cast Iron /WCB/MS/CF8/CF8M/ CF3/ CF3M/CF3M/4A/5A & other special exotic Alloys.
“QTC BRAND “ STRAINER CAST IRON – “Y” TYPE BOLTED COVER FLANGE END TABLE - D
BODY : CI- IS 210 Gr FG 200/220
SCREEN : SS 304
MFG STD : QTC
INSP & TEST STD : QTC
ENDS : FLANGED TO ANSI B 16.5 D TABLE
HYD-TEST PRESS : BODY : 213 Psig (15 Kg/Cm2)
Looking for "Industrial Strainers" ?
